單機設備
Stand alone equipment
設備描述
It includes single-layer storage tank series, double-layer vertical mixing tank series, three-layer vertical mixing cold and hot tank series.  It can be used as liquid storage tank, mixing tank, temporary storage tank, water storage tank, etc. It is suitable for food, dairy products, juice drinks, medicine, chemical industry and biological engineering, etc.  Double layer tank with heat preservation function, three layer tank with heat preservation and heating function.
architectural feature
The structure design is extremely humanized and maneuverable;  The inner wall transition section of the cylinder adopts arc transition to ensure no dead Angle.
technical specification
有效容積L 筒體尺寸D×H (mm) 總高H (mm) 進出料口徑 電機功率 攪拌速度(r/min)
500 840×1000 2750 38 0.55 常用轉速35、43、60,也可選用無極變速減速機,或者雙速減速機
800 950×1220 3000 38 0.55
900 1010×1220 3000 38 0.55
1000 1060×1500 3150 51 0.75
1500 1160×1500 3350 51 0.75
2000 1340×1500 3410 51 1.1
3000 1410×2000 4000 51 1.5
4000 1620×2000 4250 51 1.5
5000 1810×2000 4300 51 2.2
6000 1980×2000 4550 51 2.2
7000 1930×2440 5000 51 2.2
8000 2060×2440 5000 51 3
9000 2180×2440 5050 51 3
10000 2300×2440 5050 51 3
12000 2270×3000 5600 51 4
15000 2530×3000 5700 51 4
20000 2640×3660 6400 51 5.5
The configuration of tank
Quick-opening manhole, various types of CIP cleaners, fly proof sanitary breathable cover, adjustable triangle legs, detachable feed tube kit, thermometer (non-standard custom), ladder (non-standard custom), paddle mixer, level gauge and level control (non-standard custom), vortex shield.
成品展示
